Commodity heat shrink packaging machine

Overview:

Daily necessities heat shrink packaging machine uses shrink film to wrap the product or package outside. After heating, the shrink film shrinks and wraps the product or package, fully showing the appearance of the item, improving the product's displayability, and increasing the beauty and sense of value. The items packaged by the heat shrinking machine can be sealed, moisture-proof, and pollution-proof, and protect the product from external impact. It has buffering properties, especially when packaging fragile products, it can prevent the utensils from flying when broken. In addition, the possibility of product being dismantled and stolen can be reduced.

Commodity heat shrink packaging machine WH-600 can be used for automatic  shrink packaging of products. Automatic feeding can be selected. The film can be folded in half and can be sealed on three sides. It can improve product grade, protect product appearance, waterproof and dustproof functions. The speed of this machine is 60-200 bags/min, and the packaging speed is determined according to the size of the specific product.

Performance characteristics:

Sealing system:

Heating source: stainless steel heating tube with long service life

Sealing knife: Adopt anti-sticking and high temperature resistant alloy sealing knife, the outside of the knife is coated with Teflon non-stick film

Sealing knife temperature control: adopt Japanese "OMRON" digital display temperature controller and imported heat sensitive response control, temperature 0-400`C adjustable

Sealing knife protection: adopt German brand. Effectively prevent mis-sealing of packaging objects

Motor: Japanese double frequency conversion or servo motor control horizontal sealing to ensure firm and stable sealing and low noise during sealing

Slide rail: adopt Japan: "THK" to ensure smooth operation of sealing knife up and down

Cylinder: "FESTO" cylinder is used to ensure firm and accurate sealing

Conveyor system:

Belt: German Sieglin PU conveyor belt

Motor: Japan "Hanshin" guarantees stable transportation

Inverter: Japan "MITSUBISHI" controls the front and rear belt conveyor speed

Detection: US "Bonner" photoelectric sensor is used to accurately and sensitively detect product delivery and stop

There are two system configurations: double frequency conversion control system and triple servo control system, two solutions!

Finished product display:

Scope of application:

     Daily necessities shrink packaging machine is suitable for shrink packaging of large quantities of products in software, food, cosmetics, printing, pharmaceutical and flooring, ceramics, beverages, hardware and other industries.
